CB 150 2018| -Nur


NOMOR PARTDESCRIPTION
53230K15920ZABRIDGE, FORK TOP
40546K45N00ZACAP, SWINGARM END
83710K15600MSRCOWL,L REAR (MT SO RED)
83610K15600MSRCOWL,R REAR (MT SO RED)
83450K15600COWL RR CENTER
61303K15920ZBCOWL L FR SIDE(MT GN BL)
83640K15600ZACOWL,L SIDE
61302K15920ZBCOWL R FR SIDE(MT GN BL)
83540K15600ZACOWL,R SIDE
8010AK15920FENDER,REAR ASSY
61100K15920ZFFENDER,FR (MT SO RED)
42615K45N00ZBFLANGE FINAL, DRIVEN (MA AX GY)
50325K15920ZAGRIP, L REAR MAT AXIS GREY METALLIC
50315K15920ZAGRIP, R REAR MAT AXIS GREY METALLIC
53130K15920ZAHOLDER COMP., HANDLE UPPER
53133K15920ZAHOLDER, L. HANDLE UNDER
53132K15920ZAHOLDER, R. HANDLE UNDER
86102K15920ZAMARK, HONDA(65MM)
50275K15600ZAPANEL, L SHROUD (MT SO RED)
50270K15600ZAPANEL, R SHROUD (MT SO RED)
53100K15600ZAPIPE STRG HANDLE (MA AX GY)
77200K15600ZASEAT COMP,DOUBLE TYPE 1
50265K15600MSRSHROUD,L (MT SO RED)
50260K15600MSRSHROUD,R (MT SO RED)
17510K15920MSRTANK COMP,FUEL (MT SO RED)
64320K15600MGBCOWL,UNDER CENTER (MT GN BL)
86831K15660ZAMARK,CB150R TYPE 1
86101K15930ZAMARK, HONDA(60MM)
86102K15920ZAMARK, HONDA(65MM)
86202K15610ZAMARK, L WING 80 MM TYPE 2
86201K15610ZAMARK, R WING 80 MM TYPE 2
86641K15610ZBMARK,6 SPEED DOHC TYPE 1



871X0K15620ZAL STRIPE SET L (WINNING RED)
871X0K15620ZAR  STRIPE SET R (WINNING RED)


NOMOR PARTDESCRIPTION
53230K15920ZABRIDGE, FORK TOP
40546K45N00ZACAP, SWINGARM END
83710K15600WRDCOWL,L REAR (WN RD)
83610K15600WRDCOWL,R REAR (WN RD)
83450K15600COWL RR CENTER
61303K15920ZCCOWL L FR SIDE(RO WH)
83640K15600ZACOWL,L SIDE
61302K15920ZCCOWL R FR SIDE(RO WH)
83540K15600ZACOWL,R SIDE
8010AK15920FENDER,REAR ASSY
61100K15920ZAFENDER FR(WN RD)
42615K45N00ZBFLANGE FINAL, DRIVEN (MA AX GY)
50325K15920ZAGRIP, L REAR MAT AXIS GREY METALLIC
50315K15920ZAGRIP, R REAR MAT AXIS GREY METALLIC
53130K15920ZAHOLDER COMP., HANDLE UPPER
53133K15920ZAHOLDER, L. HANDLE UNDER
53132K15920ZAHOLDER, R. HANDLE UNDER
86102K15920ZAMARK, HONDA(65MM)
50275K15600ZBPANEL, L SHROUD (WN RD)
50270K15600ZBPANEL, R SHROUD (WN RD)
53100K15600ZAPIPE STRG HANDLE (MA AX GY)
77200K15600ZASEAT COMP,DOUBLE TYPE 1
50265K15600WRDSHROUD,L (WN RD)
50260K15600WRDSHROUD,R (WN RD)
17510K15920WRDTANK COMP, FUEL
64320K15600RSWCOWL,UNDER CENTER (RO WH)







871X0K15600ZAL STRIPE SET L (BLACK TYPE 2)
871X0K15600ZAR STRIPE SET R (BLACK TYPE 2)


NOMOR PARTDESCRIPTION
53230K15920ZABRIDGE, FORK TOP
40546K45N00ZACAP, SWINGARM END
83710K15600FMBCOWL,L REAR (BLK)
83610K15600FMBCOWL,R REAR (BLK)
83450K15600COWL RR CENTER
61303K15920ZDCOWL L FR SIDE(BLK)
83640K15600ZACOWL,L SIDE
61302K15920ZDCOWL R FR SIDE(BLK)
83540K15600ZACOWL,R SIDE
8010AK15920FENDER,REAR ASSY
61100K15920ZDFENDER FR(BLK)
42615K45N00ZBFLANGE FINAL, DRIVEN (MA AX GY)
50325K15920ZAGRIP, L REAR MAT AXIS GREY METALLIC
50315K15920ZAGRIP, R REAR MAT AXIS GREY METALLIC
53130K15920ZAHOLDER COMP., HANDLE UPPER
53133K15920ZAHOLDER, L. HANDLE UNDER
53132K15920ZAHOLDER, R. HANDLE UNDER
86102K15920ZAMARK, HONDA(65MM)
50275K15600ZDPANEL, L SHROUD (BLK)
50270K15600ZDPANEL, R SHROUD (BLK)
53100K15600ZAPIPE STRG HANDLE (MA AX GY)
77200K15600ZASEAT COMP,DOUBLE TYPE 1
50265K15600FMBSHROUD,L (BLK)
50260K15600FMBSHROUD,R (BLK)
17510K15920FMBTANK COMP, FUEL


871X0K15600ZBR STRIPE SET R (BLACK TYPE 1)
871X0K15600ZBL STRIPE SET L (BLACK TYPE 1)

NOMOR PARTDESCRIPTION
53230K15920ZABRIDGE, FORK TOP
40546K45N00ZACAP, SWINGARM END
83710K15600FMBCOWL,L REAR (BLK)
83610K15600FMBCOWL,R REAR (BLK)
83450K15600COWL RR CENTER
61303K15920ZDCOWL L FR SIDE(BLK)
83640K15600ZACOWL,L SIDE
61302K15920ZDCOWL R FR SIDE(BLK)
83540K15600ZACOWL,R SIDE
8010AK15920FENDER,REAR ASSY
61100K15920ZDFENDER FR(BLK)
42615K45N00ZBFLANGE FINAL, DRIVEN (MA AX GY)
50325K15920ZAGRIP, L REAR MAT AXIS GREY METALLIC
50315K15920ZAGRIP, R REAR MAT AXIS GREY METALLIC
53130K15920ZAHOLDER COMP., HANDLE UPPER
53133K15920ZAHOLDER, L. HANDLE UNDER
53132K15920ZAHOLDER, R. HANDLE UNDER
86102K15920ZAMARK, HONDA(65MM)
50275K15600ZDPANEL, L SHROUD (BLK)
50270K15600ZDPANEL, R SHROUD (BLK)
53100K15600ZAPIPE STRG HANDLE (MA AX GY)
77200K15600ZASEAT COMP,DOUBLE TYPE 1
50265K15600FMBSHROUD,L (BLK)
50260K15600FMBSHROUD,R (BLK)
17510K15920FMBTANK COMP, FUEL



871X0K15610ZAL STRIPE SET L (GUNPOWDER BLACK)
871X0K15610ZAR STRIPE SET R (GUNPOWDER BLACK)
NOMOR PARTDESCRIPTION
53230K15920ZABRIDGE, FORK TOP
40546K45N00ZACAP, SWINGARM END
83710K15600MGBCOWL,L REAR (MT GN BL)
83610K15600MGBCOWL,R REAR (MT GN BL)
83450K15600COWL RR CENTER
61303K15920ZBCOWL L FR SIDE(MT GN BL)
83640K15600ZACOWL,L SIDE
61302K15920ZBCOWL R FR SIDE(MT GN BL)
83540K15600ZACOWL,R SIDE
8010AK15920FENDER,REAR ASSY
61100K15920ZBFENDER FR(MT GN BL)
42615K45N00ZDFLANGE SUB ASSY, DRIVEN
50325K15920ZAGRIP, L REAR MAT AXIS GREY METALLIC
50315K15920ZAGRIP, R REAR MAT AXIS GREY METALLIC
53130K15920ZAHOLDER COMP., HANDLE UPPER
53133K15920ZAHOLDER, L. HANDLE UNDER
53132K15920ZAHOLDER, R. HANDLE UNDER
86102K15920ZAMARK, HONDA(65MM)
50275K15600ZCPANEL, L SHROUD (MT GN BL)
50270K15600ZCPANEL, R SHROUD (MT GN BL)
53100K15600ZAPIPE STRG HANDLE (MA AX GY)
77200K15600ZASEAT COMP,DOUBLE TYPE 1
50265K15600MGBSHROUD,L (MT GN BL)
50260K15600MGBSHROUD,R (MT GN BL)
17510K15920MGBTANK COMP, FUEL
64320K15600MGBCOWL,UNDER CENTER (MT GN BL)
86505K15610ZBMARK,STREETFIRE TYPE 1
86641K15610ZBMARK,6 SPEED DOHC TYPE 1
86102K15920ZAMARK, HONDA(65MM)
86202K15610ZBMARK, L WING 80 MM TYPE 1
86201K15610ZBMARK, R WING 80 MM TYPE 1
